Home > Tent > Arcum Tent
Plofile: Hard pressed extruded Aluminium 6061/T6(15HW)
PVC: Double PCV-coated polyester textile,flame retardant to NFPA701,f-13101 B1 M2
Connector: Strong hot-dip galvanized steel
Temperture allowed: -30 degree Celsius ) to +70 degree Celsius
Wind load Max 100 km/h, 0.3kn/sqm
Span: 3M-10M
Length: Unlimited
| Span | Eave high | Total high | Main plofile(mm) | Bay distance(m) | Roof and side PVC color/ option |
| 3M | 2.7M | 3.6M | 84*48 | 3 | 850g,650g,550g/sqm, transparent,colorful and white etc; PVC-coated polyester textile,flame retardant to DIN 4102 B1,M2,CFM. |
| 4M | 2.7M | 4M | 84*48 | 3 | |
| 5M | 2.7M | 4.3M | 84*48 | 3 | |
| 6M | 2.7M | 4.6M | 84*48 | 3 | |
| 8M | 2.7M | 5.2M | 84*48 | 3 | |
| 10M | 2.7M | 5.8M | 84*48 | 3 |
