Plofile: Hard pressed extruded Aluminium 6061/T6(15HW)
PVC: Double PCV-coated polyester textile,flame retardant to NFPA701,f-13101 B1 M2
Connector: Strong hot-dip galvanized steel
Temperture allowed: -30 degree Celsius to +70 degree Celsius
Wind load Max: 100 km/h , 0.3kn/sqm
Snow loading:75kg/sqm
Span: 3-50M
Length: Unlimited
| Span | Eave high | Total high | Main plofile(mm) | Bay distance(m) | Roof slope(degree) | Roof and side PVC color/ option |
| 3M | 2.7M | 3.2M | 84*48 | 3 | 22 | 850g,650g,550g/sqm, transparent,colorful and white etc; PVC-coated polyester textile,flame retardant to DIN 4102 B1,M2,CFM. |
| 4M | 2.7M | 3.4M | 84*48 | 3 | 22 | |
| 5M | 2.7M | 3.6M | 84*48 | 3 | 22 | |
| 6M | 2.7M | 3.8M | 121*68 | 3 | 22 | |
| 7M | 2.7M | 4.0M | 121*68 | 3 | 22 | |
| 8M | 2.7M | 4.2M | 121*68 | 3 | 22 | |
| 9M | 2.7M | 4.4M | 255*115 | 3 | 22 | |
| 10M | 2.7M | 4.6M | 300*125 | 3 | 22 |
Small aluminum tents as a temporary mobile construction,can be widely used in various occasions, such as temporary stores,points of sales,it?has a convenient demolition,easy installation, anti-wind up to 100km/hour,can be used repeatedly and so on,Compared to other simple type of folding tent with?poor quality,low grade, low utilization,this kind of tents more grade,thereby enhancing the business product level,100% space utilization,repeatable multiple use,artificial preservation of the situation,Life expectancy of up to 5-8 years,to meet the needs of various businesses on different occasions to sell at the same time,the seller?can also print their products or company name on the top fabric,which can?promote?their own products and Brand better,attract more customers.
